NEW: C5 LGM Longtube Header Install

The headers are a full 32” True Long Tube header that has been dubbed, "The most powerful C5 header on the Planet”! This header includes a complete header with a 3/8” flange and incorporates a “Race Style Merge Collector”, to a full 3” X pipe, and continues in 3” right up to the original 2 bolt muffler flanges. This makes this a full bolt on application that requires NO cutting or welding, and leaves the factory system completely intact incase you ever want to easily put the car back to stock. (C5) More...

Est 3-8hours

Meziere LS1 Electric Water Pump (F-Body Version) For years talk of electric water pumps had been circulating through the LS1 community, and finally Meziere has delivered. Whether you are a hard core drag racer who wants to just cool the car in the pits and staging lanes, an enthusiast who's itching for more power from his heads/cam car, or just a basic bolt on type of guy, an electric water pump is probably for you. (F-Body) More...   281036 views Est 1-6hours

LGM Wilwood C5 Front Brake Package For C5 Corvette enthusiasts looking for more stopping power either at the track or on the street, Wilwood has the solution. In this install I'll put on a pair of of huge 6 piston Wilwood calipers and some nice 2 piece wilwood rotors from LGM on the front of a C5. Not only does it look amazing, it performs. (C5) More...   228739 views Est 2-6hours

Did you know?

Only '98 through '00 LS1`s that came in an F-Body had EGR. 2001 and up F-bodies did not have an EGR system. No LS1/LS6 Corvettes ever came with EGR.

F-Body Cam and Valvespring Swap By far, one of the best mods you can possibly ever do to your LS1/LS6 is to install an aftermarket camshaft in it. Here I go through the whole process of selecting and installing an aftermarket camshaft, along with the various valvetrain upgrades that are required. Frequently asked cam related questions are also answered. (F-Body) More...   2340336 views Est 3-12 hours

LS1 Head Swap Finally I dug in and did a headswap on an LS1. This turned out to be VERY easy, but a lot of work. I strongly recommend you have a helper during this install, and all the recommended tools listed on the page. Anybody that can turn a wrench (and not get frustrated when something goes wrong) can do this install no problem. (F-Body) More...   666478 views Est 8-12 hours (1 hour additional if doing a cam swap)

Infopic: How to port your throttlebody

First do some preliminary porting, making sure you DONT port right at the opening where the blade contacts when shut. Grind down the ridge thats about 1/2" in front of the blade and try to smooth it all out. Then, use JB weld to fill in the big port making sure the epoxy gets DEEP into the hole and wraps around inside the hole so once it sets, it can never fall out. Let it dry, then smooth the epoxy out and drill the hole in the epoxy for the PCV hose. On an F-body, you'll need to drill two holes. The Ybody only needs one. Click for full image

BMR Swaybar Install If you've been fortunate enough to drive a true modern sports car, you probably noticed how tight and responsive the car felt. While the F-body may not be a true sports car, you can get it one step closer by upgrading the suspension. One of the key parts of the suspension is the stabilizer bar, a.k.a the anti-swaybars or "swaybars" for short. Here I'll detail how to remove and replace your stock bars for a set of aftermarket ones. (F-Body) More...   300018 views Est 2-3 hours

C5 Blackwing Install As most people know, one of the easiest ways to make more horsepower is by replacing the air induction system. In this article I'll detail the very simple removal of the stock air induction system and the installation of the Donaldson Blackwing air filter. (C5) More...   264719 views Est 30min-1hour
